Our range of drone detection devices with incorporated jamming/spoofings function are used to detect and track almost all models of commercially available drones.
RoarkSJ Series
The RoarkSJ Series device offers both man portable and sentry modes, 8-15KM detection range on 433. 800.900.1.4 .2.4 5.2 5.8 .Wifi Bands & 3KM jamming range on 900.1.5 2.4 5.2 5.8 bands.
Size: Length 410mm, Width 330mm, Height 190mm excluding antenna
Weight: 14KG
Power Supply: 220V AC, can be connected by fixed power supply or UPS.
Voltage: AC100V～240V
Consumption: 15W
Detection Range: Up to 10KM depending on location.
The device can detect DJI (including Mavic 3, Mavic 2, Mavic Mini2, Mavic Air, Mavic Air2, Mavic miniSE, Mavic Pro, Mavic Air2S, Mavic mini, Phantom 4Pro, Phantom 4ProV2.0,Genie 4, Tello and other models), Autel, Xiaomi, Dahua, Hikivision,FUTABA, Hubson, EHang, Yuneec, Zerodu, Weili, Zhendi, Huakor, Sima, Cornerstone, Yunke, Chasing Cloud, Pudu, Holystone, AEE, Feipai, Youdi, Pegasus, Keweitai, Dagong, Corbett, UAV signals from JOUAV, Parrot, 3DR, CFLY,
TW and other brands
With positioning function, it can display the working frequency band, brand number, electronic fingerprint ID (serial number of the fuselage), bearing, distance, latitude and longitude , flight altitude and other information of the drone in the detection list, and it can display identification icons and flight tracks (adsb) on the Plexus overlay.
With the remote control (pilot) detection and positioning function, the remote control can be displayed in the detection list. (Pilot) latitude and longitude , distance, bearings and other information, and can display identification icons and movement tracks on Plexus.
Detects over 20 drones simultaneously from over 10 different brands
Price: $51,800 inc Shipping
RoarkDF Series
Suitcase based design variant performing the same functionality as the SJ Series without the jamming element.
Performance parameters
Detection frequency band: 900MHz, 1.4GHz, 2.4GHz, 5.2GHz, 5.8GHz (expandable and customizable)
Detection distance: From 0km-15KM Depending on location
Detection quantity: ≥20 times (simultaneously)
Number of tracks: ≥10 times (simultaneously)
Power supply: built-in lithium battery or AC input
Battery life: ≥12 hours (full power)
Equipment size: 470mm*357mm*176mm (±2mm)
Working temperature: -40℃~65℃
Equipment weight: <13kg
Protection level: IP66 (closed state)
Price $48,600 inc shipping
Roark Handheld Series
The system is developed based on CRPC+ message-level protocol parsing technology and is equipped with a comprehensive UAV command and control platform. It can conduct real-time monitoring and early warning of UAVs within the detection range, and accurately display the target UAV’s fuselage serial number, model, location, speed, altitude, track, remote control location and other information.
Performance parameters
Detection frequency band: 2.4GHz, 5.8GHz
Detection radius: 0~3km
Positioning accuracy: ≤2m (RMS)
Detection quantity: ≥10 times (simultaneously)
Number of tracks: ≥10 times (simultaneously)
Motion detection: moving speed ≥ 60km/h
Battery life: ≥4h
Equipment size: 173mm*90mm*56mm (±2mm)
Working temperature: -25°C~50°C
Price $6,990 inc shipping
RoarkDS Range
Offers full detection, tracking and monitoring services alongside integrated spoofing for covert detection and disruption services.
Performance parameters
Detection frequency band: 30MHz~6GHz
Key frequency bands: 400MHZ, 800MHZ, 900MHZ, 1.4GHZ, 2.4GHz, 5.2GHz, 5.8GHz (customizable)
Detection radius: 0~15km
Spoofing Range: 3KM
Detection range: 360° full airspace
Direction finding accuracy: 3°(RMS)
Transmitting frequency band: GPS-L1, GLONASS-L1 (BDS-B1/Galileo-E1/L2 optional)
Transmitting power: <10mW
Control radius: 500m~1000m (customizable)
Working temperature: -40℃~70℃
Protection level: IP66
Price $52,800 inc shipping
